Preassembled Doors
• 20 gauge galvanealed, insulated door leaf with painted inish coat
• 16 gauge galvanealed, reinforced top and bottom channels
• 16 gauge galvanealed, subframe (framed opening)
• Subframe material is paintable for finishing purposes
Knock Down Doors
• Door leaf is made of hot dipped galvanized 20 gauge steel
• Door frame is made of 16 gauge galvanized steel
• Frame package includes a Grade 2 lever lockset or upgrade
• Bronze or White available colors
• Available wind rated to 150 mph
Door Canopies
• Constructed of 26 gauge material around 18 gauge galvanized frame
• Telescoping channels mount between girts on interior of building
• Canopy drains against building to the outside of the door jambs
• Standard sizes 4’ 6” x 4’ for 3070 door, 7’6” x 4’ for 6070 door
• White color available
Non-Thermal Windows
• Single or insulated glass
• Horizontal slide or ixed
• Aluminum frame with bronze inish
• Self-lashing / Self-framing feature
Preassembled Thermal Windows
• Thermal-break frame
• Self-lashing / Self-framing feature
• Insulated glass
• White or bronze
Several sizes and styles to choose from:
• Horizontal sliding window
• Slider-ixed-slider window
• Fixed picture window
• Vertical slider or single hung
• Fixed / Project-in window
Roof Panel
Vertical standing seam roof panels are ideal for new construction or
retroit applications with a panel width of 16”. Panels contain factory-applied
sealant and are notched and swaged at the endlaps. Panels are available in
24 or 22 gauge steel
Roof Panel Plus
Vertical standing seam roof panels are similar to above
panels with the exception that they are field seamed with a double-lock,
360 degree seam during installation using an electric seaming machine.
Panels are available in 24 or 22 gauge steel.
Dektites
• Long life, flexible, weatherproof EPDM rubber
• Flexible, corrosion resistant aluminum base conforms to any panel coniguration
• High temperature silicone material and retrofit available
Curbs
• 18 gauge Galvalume or Aluminized Steel
• Corners mitered and welded watertight
• Welds prime painted after fabrication
• Fully welded cricket water diverter
• 8” minimum height on right side
• Separate cap cells
Ridge Vents
• Standard size 9” x 10’
• Individual or continuous run installation
• Fully protected by 4’ x 4’ mesh galvanized hardware (bird screen)
• 26 gauge exterior combined with internal components of 24, 20, 18
gauge die formed sheet metal and machined parts for long service life
• Die formed or lat skirt
• Galvalume or white colors available
Low Proile Ridge Vent
• Each 10’ unit features 180 sq. inches of free area with base rating of
450 cfm’s of air movement
• Vents are made to match roof slope to maintain low proile appearance
All steel • parts are 24 gauge
• Vent features the Cor-A-Vent ventilation core a time tested,
economical, self-cleaning and durable core
• Die formed or lat skirt
• Galvalume or white color available
Louvers
• Frames 18 gauge galvanized steel
• Blades 20 gauge roll formed galvanized steel
• Self-mulling, self-framing and self-lashing
• Insect screen aluminum mesh in aluminum frame
• Available ixed or adjustable
• Standard operator is reinforced cast aluminum hand crank
• Chain operator upon request
• White and bronze colors available
